Tungsten Copper

Item Code: Features:
  • Description

Tungsten Copper:

Tungsten-Copper alloy is the composite of Tungsten and Copper, which own the excellent performances of Tungsten and Copper, such as heat-resistant, ablate-resistant, high-intensity, excellent thermal and electrical conductivity. It is easy to be machined. It is used widely in such industries as engine, electrical power, electron, metallurgy, spaceflight and aviation. Using CIP formation, sintered tungsten skeleton and infiltrating copper (silver) technology, large size and special shape products of tungsten-copper (silver) composites with 6-90 percent of copper are produced, such as electric contacts, electrode, refractory parts, heat sinks and parts of rocket, We can also produce sheet material, tubing, plate and other small products by mould pressing, extrusion pressing and MIM.

Main Specifications of W-Cu Composite:

Type

Density
g/cm3

Conductivity
%IACS

HB
MPa

Size
mm

WCu50

11.9~12.3

=55

1130~1180

Tube: Ø3~390
Length<500
Sheet:
Width<390
Length<500
Special type:
Width<390
Length<500

WCu40

12.8~13.0

=47

=1375

WCu30

13.8~14.4

=42

=1720

WCu20

15.2~15.6

=34

=2160

WCu10

16.8~17.2

=27

=2550

WCu7

17.3~17.8

=26

=2900
